PreSonus Studio 24c USB錄音介面


NT$5,700 NT$6,840

PreSonus Studio 24c USB錄音介面

無論是臥室音樂人或長期旅行的創作者,你值得專業級的錄音品質。

PreSonus Studio 24c USB錄音介面

規格說明
一般

Sample Rates(取樣率):44.1, 48, 88.2, 96, 176.4, or 192 kHz

Converter Resolution(轉換器訊號解析度):24 bit

ADC Converter Dynamic Range(類比數位轉換器動態範圍):108 dB

DAC Converter Dynamic Range(數位類比轉換器動態範圍):108 dB

麥克風輸入

Maximum Level(最大音量):+10 dBu (±0.5 dBu, min gain)

Gain Range(增益範圍):50 dB

Frequency Response(頻率響應):20 Hz – 20 kHz (±0.3 dBu, unity gain, unwtd)

Dynamic Range(動態範圍):106 dB (A-wtd, min gain)

THD + N(總諧波失真+雜訊):0.004% (1 kHz, -1 dBFS, min gain)

EIN:-126 dBu (A-weighted, 150Ω, max gain)

Input Impedance(輸入阻抗):1.4 kΩ

Phantom Power(幻想電源):+48 VDC (10 mA total)

樂器輸入

Maximum Level(最大音量):+19 dBu (min gain)

Gain Range(增益範圍):50 dB

Frequency Response(頻率響應):20 Hz – 20 kHz (±0.1 dBu, unity gain, unwtd)

Dynamic Range(動態範圍):105 dB (A-wtd, unity gain)

THD + N(總諧波失真+雜訊):0.002% (1 kHz, min gain)

Input Impedance(輸入阻抗):750 kΩ

主要輸出

Type(插孔規格):6.3 mm TRS, Female

Maximum Level(最大音量):+10 dBu (1 kHz, unity gain, balanced)

Frequency Response(頻率響應):20 Hz – 20 kHz (±0.3 dBu, unity gain, unwtd)

Dynamic Range(動態範圍):104 dB (unity gain, unwtd)

THD + N(總諧波失真+雜訊):0.001% ( 1 kHz, -1 dBFS, unity gain)

耳機輸出

Maximum Power(最大功率):47 mW / channel @ 56Ω

Frequency Response(頻率響應):20 Hz – 20 kHz (±0.5 dBu, unity gain, unwtd)

Dynamic Range(動態範圍):83 dB (A-wtd, 56Ω load)

THD + N(總諧波失真+雜訊):0.01% (1 kHz, 0 dBFS, loaded)

Impedance Working Range(阻抗工作範圍):32Ω to 300Ω

粉絲頁直接詢問 :

反拍樂器 FB

回首頁

PreSonus Studio 24c USB錄音介面

PreSonus Studio 24c USB錄音介面

Whether you’re recording your first album or your hit podcast’s latest episode, the Studio 24c will help you sound your best. With two of PreSonus’ pristine XMAX-L mic preamps for recording vocals; plus high headroom instrument preamps so you can connect your guitar or bass right to your interface; and professional input metering so you can keep track of your recording levels, the Studio 24c delivers amazing sound quality in a rugged, compact form factor. A complete home recording studio right out of the box, the Studio 24c audio interface comes with a complimentary license of PreSonus’ award-winning Studio One® Artist music production software, so you can get recording right away.

產品規格:

  • 2 in/2 out USB 錄音介面
  • 搭載 2 個 XMAX-L 前級放大器的 Mic/ /instrument 輸入
  • 最高解析度 192 kHz
  • /TRS Outputs、headphone 輸出
  • MIDI In/Out
  • 4 個 LED 顯示 VU 表
  • 完美搭配 Windows 及 Mac 上的 DAWs
  • 附贈 Studio One 4 Artist 音樂編曲軟體
